| Quantity: | |
|---|---|
LC-04
Ulink
Application：
It is suitable for cleaning, shaking and draining leafy vegetables, roots and stems, pickled fruits and vegetables, such as: cabbage, lettuce, cabbage, pickled radish, rutabaga, etc. It is also mostly used in conjunction with other clean vegetable processing equipment to assemble into a production line.
Item features：
Adapted a swirling-flow with bubbles cleaning design, a high-pressure gas injection pipe is arranged at the bottom of the cylinder, and the high-pressure bubbles can effectively separate the vegetables into clumps, which effectively solves the clumping caused by the pure whirlpool vegetable washing machine when cleaning uncut vegetables.only the defects of the materials after cutting can be cleaned. The exhaust pipe is equipped with a pressure relief valve to adjust the bubble strength when cleaning different materials. The eddy current cleaning machine adopts 360-degree cycle flipping massage cleaning + high-pressure adjustable bubble vibration cleaning, which has good cleaning effect and does not damage the materials.
Using vibratory conveying instead of traditional conveyor belt conveying has a simpler structure, reduces a lot of cleaning time than traditional conveyor belts, and is more convenient to use; the conveying surface in contact with the material is designed with punched holes, which effectively separates the debris in the material. The imported vibrating arm is adopted, the vibration frequency is high and stable. At the same time, the vibrating screen is equipped with a double-row spray system to form a high-density spray belt to ensure that during the continuous and stable vibration conveying process, the upper spray and the lower vibration are used to make The material is cleaned more cleanly, and the excess water is effectively drained, and the pre-dewatering function is provided for the next dewatering process.
Automatic water replenishment and water-free power-off functions greatly reduce the machine failure rate. The circulating water tank and the main water tank are equipped with automatic water replenishment devices without manual intervention, which is convenient and efficient, and effectively saves water.
According to customer needs, it can be equipped with ozone disinfection system, slag discharge device, etc., to form a complete cleaning and removal of impurities, disinfection and removal of pesticide residues.
The design of the whole machine is reasonable and the cleaning effect is good. It is an indispensable vegetable washing machine in vegetable washing equipment. Remarks: Product Technical Data and functional devices can be customized or matched according to the actual needs of customers.
Technical Data：
Machine size | Capacity | Weight | Voltage | Power |
4200*1460*1850 | 1000kh/h | 300kg | 380V | 6.46kw |
Application：
It is suitable for cleaning, shaking and draining leafy vegetables, roots and stems, pickled fruits and vegetables, such as: cabbage, lettuce, cabbage, pickled radish, rutabaga, etc. It is also mostly used in conjunction with other clean vegetable processing equipment to assemble into a production line.
Item features：
Adapted a swirling-flow with bubbles cleaning design, a high-pressure gas injection pipe is arranged at the bottom of the cylinder, and the high-pressure bubbles can effectively separate the vegetables into clumps, which effectively solves the clumping caused by the pure whirlpool vegetable washing machine when cleaning uncut vegetables.only the defects of the materials after cutting can be cleaned. The exhaust pipe is equipped with a pressure relief valve to adjust the bubble strength when cleaning different materials. The eddy current cleaning machine adopts 360-degree cycle flipping massage cleaning + high-pressure adjustable bubble vibration cleaning, which has good cleaning effect and does not damage the materials.
Using vibratory conveying instead of traditional conveyor belt conveying has a simpler structure, reduces a lot of cleaning time than traditional conveyor belts, and is more convenient to use; the conveying surface in contact with the material is designed with punched holes, which effectively separates the debris in the material. The imported vibrating arm is adopted, the vibration frequency is high and stable. At the same time, the vibrating screen is equipped with a double-row spray system to form a high-density spray belt to ensure that during the continuous and stable vibration conveying process, the upper spray and the lower vibration are used to make The material is cleaned more cleanly, and the excess water is effectively drained, and the pre-dewatering function is provided for the next dewatering process.
Automatic water replenishment and water-free power-off functions greatly reduce the machine failure rate. The circulating water tank and the main water tank are equipped with automatic water replenishment devices without manual intervention, which is convenient and efficient, and effectively saves water.
According to customer needs, it can be equipped with ozone disinfection system, slag discharge device, etc., to form a complete cleaning and removal of impurities, disinfection and removal of pesticide residues.
The design of the whole machine is reasonable and the cleaning effect is good. It is an indispensable vegetable washing machine in vegetable washing equipment. Remarks: Product Technical Data and functional devices can be customized or matched according to the actual needs of customers.
Technical Data：
Machine size | Capacity | Weight | Voltage | Power |
4200*1460*1850 | 1000kh/h | 300kg | 380V | 6.46kw |
